EPOXY diëlectrische gietharsen voor toepassing ingieten van elektronica en elektrische componenten

DIELECTRICS / EPOXY

flexible
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 22801 / RE 2120


Electrical insulating epoxy resin. bi-component, semi flexible, good thermal ageing stability. D 62 3500 1.47 100 / 20 Casting resin for mechanical & numerous electrical applications, especially for low or medium voltage (capacitors, tranformers, filters).



semi-rigid
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 22801 / RE 2050


Semi-rigid epoxy resin. Good thermal ageing stability, bi-component. D 80 4200 1.53 100 / 11 Numerous electrical applications, especially for low or medium voltage.



rigid
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 22891 / RE 22891


Flame retardant properties. Long cure rate. Chemical resistance. High temperature resistance. A slightly rigid version of RE 22801. D 88 3000 1.49 100 / 12 Multipurpose: electric motors, transformers, coils, relays.



very rigid
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 22904 / RE 22904


Electrical insulating epoxy resin. Long pot life at room temperature , good behaviour at thermal shocks & low CTE. D 92 3500 1.56 100 / 13 Casting resin for mechanical and numerous electrical applications especially for low or medium voltage.



heat cure
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 22850 / RE 31100


Low viscosity. Refillable with silica. Good thermal shock resistance. High temperature resistance (150°C). Excellent for demanding applications. Two component room temperature cure, low viscosity system offering an economical potting material with excellent handling properties. Absorbs the stress of conflicting CTE’s among components. D 86 2100 1.19 100 / 80 Transport & distribution of energy. High voltage coil systems & parts needing thermal resistance.

RE 42915 - 92


Heat & chemical resistance. Excellent dimensional stability. Equivalent to RE 22904 in single system formulation. D 91 2800 (60 °C) 1.6 1 part Automotive encapsulation under the hood.
Polyurethaan diëlectrische gietharsen voor toepassing ingieten van elektronica en elektrische componenten



DIELECTRICS | POLYURETHANE



flexible
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 11550 / RE 1020


Fast processing due to rapid-cure speed. Low viscosity. Fills intricate parts void-free. Low stress on embedded components. Allows flexible processing: injection moulding or machining. Excellent electrical properties over a wide range of environmental conditions. A 55 500 1.14 100 / 30 Cable connectors. Protection of connectors. Ideal for the automotive industry. Fullfills autospecification norms.

RE 11501 / RE 1020


Low stress on embedded components. U.L. Certified. The exceptional combination of a soft PU makes this resin formulation ideal for avoiding mechanical stress on components. Choice of three different potlife (handling time). A 55 2400 1.29 100 / 10 Sensitive electronic components: sensors for all transport applications

RE 11613 / RE 1040


Excellent dielectric properties. Fungus resistance. Low stress on embedded components. Excellent moisture resistance. A high quality, high-end product. A 60 2500 0.97 100 / 26 All underwater applications such as pomps. All applications for electronic components used in wet environmentsfor example, all applications where high moisture resistance is required.

RE 11820 / RE 1020


Excellent dielectric properties. Fungus resistance. Excellent moisture resistance. A high quality, high-end product. Choice of three different potlife (handling time). A 82 4500 1.10 100 / 25 Transmitter, all underwater applications such as pomps. All applications for electronic components used in wet environmentsfor example, all applications where high moisture resistance is required.



semi-rigid
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 12461 / RE 1010


U.L. Certified. Low viscosity. Good electrical heat dissipation & thermal conductivity. Available in several colors. Good humidity resistance. D 46 1100 1.55 100 / 16 General purpose . Ideal for intricate parts.

RE 12551 / RE 1020


U.L. Certified. Good electrical heat dissipation & thermal conductivity. Excellent mechanical, thermal and chemical resistance properties (130 °C). Choice of two different potlife (handling time). D 55 2400 1.55 100 / 14 Small transformers. Electronic cards. Relays. Electronic filters. Applications requiring reasonable resistance to humidity.

RE 12560 / RE 1020


General purpose resin. Ease of Processing. Low viscosity. Can be used in processing where manual application is a required. Choice of three different potlife (handling time). D 56 1400 1.33 100 / 25 Small transformers. Electronic cards. Relays. Electronic filters. Applications requiring reasonable resistance to humidity.

RE 12500 / RE 1030


General purpose resin. Good electrical heat dissipation & thermal conductivity. Economical system. D 50 2600 1.66 100 / 10 Applications which do not require highly technical specifications.

RE 12602 / RE 12602


Short time-cure speed and medium viscosity allows for thorough wetting. A convenient 1:1 by volume mix ratio. Fast setting. Doesn't run. Ideal for moisture proofing. Adheres well to most plastics and metals. D 60 THIXO. 1.30 127 / 100 Sensitive potting applications where leakages must be avoided, for example cable connections.



rigid
References Special properties Shore Hardness Viscosity ( mPa.s) Density Mix Ratio by weight Typical Applications

RE 12851 / RE 1030


Flame Retardant Properties. Electric heat dissipation & thermal conductivity. Economical system. D 85 3800 1.63 100 / 20 General purpose for all kind of transformers and capacitors.

RE 11880 / RE 1020


High temperature resistance. Low moisture absorption. Low viscosity. Excellent mechanical. Thermal and chemical resistance properties. A 88 1500 1.41 100 / 20 Ideal for automotive applications requiring heat resistance. Sesnors. Electronic devices.

RE 12885 / RE 1030


Chemical resistance. Extreme temperature performance. Excellent dielectric properties. Low viscosity. Good thermal mechanical shock resistance. Rapid cure at elevated temperatures. Excellent for demanding industrial applications. D 88 2000 1.53 100 / 40 Highly technical transformers operating in severe industrial environments (grease, moisture, etc.)

RE 12771 / RE 1010


Low viscosity. Flame retardant properties. Rapid reactivity. Fast curing for faster processing. D 77 1000 1.38 100 / 26 Applications requiring high productivity rates. Capacitors. Transformers. Relays.

RE 12800 / RE 1020


General purpose resin. Low viscosity. Good thermal mechanical shock resistance. Excellent for demanding industrial applications. D 80 1200 1.38 100 / 28 Applications requiring long manipulation time, for example manual applications. Capacitors. Transformers. Relays.

RE 12840 / RE 1010


Two-component liquid polyurethane resin, solvent free, rigid, low viscosity & high thermal conductivity. D 86 800 1.58 100 / 30 Casting resin for mechanical and numerous electrical applications especially for low or medium voltage..

PX 225


Low viscosity for easy casting Good impact and flexural resistance Very easy coloring Transparent 2.500 80 80 Thermoplastic-like parts with a flexural modulus of elasticity close to 2.500 MPa







Download de folder van dielectrische harsen
